Product Parameters:Power supply: AC110V+/-10% 60HzPower consumption: 30VASpeed: 0~200rmpAdjustment range of spit out glue: 0~999.9Adjustable range in suck back glue: 0~400Minimum spit out glue: 0.0001mlApplicable material viscosity: below 10000psProduct Features: There are two modes of use: discharge mode, stable operation mode (quantitative discharge), manual control modePacking List: dispenser mainframe x 1, Teflon tube dispensing pen x 1, Teflon tube x 1, foot switch x 1, power cord x1, instruction manual x 1.Operation Method:Manual mode:1. Install the machine, connect the power cord, and power on, find the switch from the position, the indicator light.2. Install the Teflon tube.3. Set forward and reverse to use CW and CCW keys for conversion. We select CCW key for conversion, and we select CW key for clockwise rotation.4. Set the back suction VAC ADJ to turn forward and reverse to select the required value. It is best to use manual mode to turn off the suction when reversing.5. Adjust the DIS and ADJ knobs to set the best speed (the best speed for work is 50~120RM).6. Press the "SHOT" button, or manual switch, foot switch to complete the job.Automatic mode:1. Turn the switch to the TDC position, the indicator light is on.2. Use the DISPERSE TD heart button to set the dispensing angle.Work according to the above manual mode 2, 3, 4, 5, 6 program.Note:In the state of counterclockwise rotation, the (nS T) key changes to the amount of sucked back power.
